Product details
Technical Specifications
| BRAND | Dell |
|---|---|
| STORAGE FAMILY | PowerVault |
| SERVER MODEL | MD1400 |
| FORM FACTOR | 2U Rackmount |
| NO.OF DRIVES | Upto Twelve (12) hot-pluggable 3.5-inch or 2.5-inch Drives |
| DRIVE EFFICIENCY AND CAPACITY | 3.5” NL-SAS 6Gb/12Gb HDD (7.2K): 4TB, 2TB, 1TB 3.5” NL-SAS 12Gb HDD (7.2K): 14TB, 10TB, 8TB, 6TB 2.5” SAS 12Gb HDD (7.2K): 500GB 2.5” SAS 12Gb HDD (10K): 1.8TB, 1.2TB, 600GB, 300GB 2.5” NL-SAS 12Gb HDD (7.2K): 2TB 2.5” SAS 12Gb SED (15K): 600GB 2.5” SAS 12Gb HDD (15K): 600GB, 300GB 2.5” SAS 12Gb SSD: 1.6TB, 800GB, 400GB, 200GB |
| MAX STORAGE | Upto 168TB when using (12 x 14TB) NearLine -SAS LFF HDDs |
| MAX EXPANSION CAPACITY | 8 enclosures, PCIe 3.0 (4 Enclosures / Port) |
| RAID CONFIGURATION | PERC H830 / H840 HBA RAID 0, RAID 1, RAID 10, RAID 5, RAID 6, RAID 50, and RAID 60 |
| POWER SUPPLY | AC – 600 Wattage; DC – 700 Wattage |
| DIMENSIONS (H X W X D) | 8.7 cm x 48.2 cm x 54.61 cm |
| (EMM) ENCLOSURE MANAGEMENT MODULES | 2 x EMM |
